3203-BD-2Z FAG Double Row Angular Contact Bearing - 17x40x17.5mm

Brand:
Model:

3203-BD-2Z
Availability:

IN STOCK
Trade Terms:

CIF
Payment Terms:

100% T/T or Western Union or PAYPAL in advances
Delivery Terms:

1-3 working days upon your payment
Shipping Terms:

Express Delivery or Air or Sea
Price:

Please contact Email sales@hensenbearing.com
We can provide the certificate of origin to ensure genuine products.Fast delivery , 3 years warranty
The real photos haven't been uploaded yet,please contact us by phone or email to view our detailed actual pictures.

We are a one-stop supplier of high quality bearings. We can supply the best products at the lowest price.

Product Description

This 3203-BD-2Z bearing is a metric double row angular contact bearing, with an improved internal structure. The bearing has metal dust covers on both sides, steel sheet metal retainers, and normal radial internal clearance. The size of the bearing is 17x40x17.5mm

32	03	BD		2Z
Maximum Capacity, Light Series	17mm - Bore Size	Modified Internal Construction with a 30° Contact Angle		Metal Shields on Both Sides of the Bearing	Steel Cage	Normal Internal Clearance

Product Detailed Parameter

Brand:
Model:

3203-BD-2Z
Availability:

IN STOCK
Type:

Angular Contact Ball Bearing
d - Inside diameter (mm):

17 mm
D - Outside diameter (mm):

40 mm
B - Width (mm):

17.5 mm
Weight (Kg):

0.096 Kg
Retainer type:

Steel
Seals or shields:

Two metal seals
Clearance:

Standard
Contact Angle:

30°
Cr - Basic dynamic load rating, radial (N):

15,500
Cor - Basic static load rating, radial (N):

9,500
Cur - Fatigue load limit, radial (N):

660
nG - Limiting speed (1/min):

14,600
nϑr - Reference speed (1/min):

16,600
Tmin - Operating temperature min:

-20 °C
Tmax - Operating temperature max:

120 °C

Delivery Locations	Delivery Time
Europe	1-3 Day
North america	2-4 Day
Sounth america	2-4 Day
Oceania	2-4 Day
Asia	1-3 Day
Africa	2-5 Day

Delivery Locations	Delivery Time
Europe	1-3 Day
North america	2-4 Day
Sounth america	2-4 Day
Oceania	2-4 Day
Asia	1-3 Day
Africa	2-5 Day

Hongkong Hensen Bearing Co.,Ltd is a supplier of international professional import bearing with 20 years business history, we mainly offer: SKF、FAG、INA、TIMKEN、NSK、NTN、KOYO、NACHI、IKO、FYH、ASAHI、THK original imported brand bearings, if you want to know more information or to place an order for FAG 3203-BD-2Z，Please feel free to contact me.
Our products have wide models, delivery on time, We can provide standard and non-standard products, we are committed to providing customers with high-quality pre-sale service and after-sale service. Give you high quality products and excellent service, at the lowest price provide the best quality bearings, adhere to the concept of "take the customer as the center".We listen to the user's feedback information any time, to serve our customers better and perfect.
We promise that we can offer the best products with best service to our customers. We will provide the FAG 3203-BD-2Z with best quality and competitive price for you.If you need FAG 3203-BD-2Z or other brand 3203-BD-2Z Please feel free to contact us.
Email:sales@hensenbearing.com
