NA4901-RSR-XL INA Machined Needle Roller Bearing - 12X24X13MM

Brand:
Model:

NA4901-RSR-XL
Availability:

IN STOCK
Trade Terms:

CIF
Payment Terms:

100% T/T or Western Union or PAYPAL in advances
Delivery Terms:

1-3 working days upon your payment
Shipping Terms:

Express Delivery or Air or Sea
Price:

Please contact Email sales@hensenbearing.com
We can provide the certificate of origin to ensure genuine products.Fast delivery , 3 years warranty
The real photos haven't been uploaded yet,please contact us by phone or email to view our detailed actual pictures.

We are a one-stop supplier of high quality bearings. We can supply the best products at the lowest price.

Product Description

The NA4901-RSR-XL is a Standard Duty, Single Row Machined Needle Roller Bearing with an Inner Ring and 1 Rubber Seal. The Inner Ring is separable from the Cage and Outer Ring, while the Outer Ring is fixed to the Cage and has a lubrication groove and an oil hole. Bearings with an Inner Ring are used when the shaft being used isn't heat-treated and finished by grinding. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high radial load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 12X24X13mm.

NA	49	01	RSR	XL
Single Row Caged Needle Roller Bearing	Dimension Series 49	12mm - Bore Size	1 Rubber Seal	X-Life Bearing	Including Inner Ring

Product Detailed Parameter

Brand:
Model:

NA4901-RSR-XL
Availability:

IN STOCK
Type:

Needle Roller Bearing
d - Inside diameter (mm):

12 mm
D - Outside diameter (mm):

24 mm
B - Width (mm):

13 mm
Weight (Kg):

0.027 Kg
Retainer type:

Steel
Seals or shields:

One Rubber Seals
Clearance:

Standard
Basic dynamic load rating (KN):

8.6
Basic static load rating (KN):

8.3
Fatigue load limit (KN):

1.66
Limiting speed (r/min):

13900
MAX. Operating Temperature:

120°C/248Â°F
MIN. Operating Temperature:

-30°C/-22Â°F
Raceway Diameter Inner Ring (MM):

16
Outer Ring Width (MM):

13 mm
Inner Ring Width (MM):

14 mm
