NK35/30-TV-XL INA Machined Needle Roller Bearing - 35X45X30MM

Brand:
Model:

NK35/30-TV-XL
Availability:

IN STOCK
Trade Terms:

CIF
Payment Terms:

100% T/T or Western Union or PAYPAL in advances
Delivery Terms:

1-3 working days upon your payment
Shipping Terms:

Express Delivery or Air or Sea
Price:

Please contact Email sales@hensenbearing.com
We can provide the certificate of origin to ensure genuine products.Fast delivery , 3 years warranty
The real photos haven't been uploaded yet,please contact us by phone or email to view our detailed actual pictures.

We are a one-stop supplier of high quality bearings. We can supply the best products at the lowest price.

Product Description

The NK35/30-TV-XL is a Light Duty Open Type, Single Row Machined Needle Roller Bearing. This Bearing has no Inner Ring, meaning the Needle Rollers are mounted directly onto the shaft. As such, the Bearing has better running accuracy as it isn't affected by assembling an Inner Ring with the shaft. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 35x45x30mm.

NK	35	/30	TV	XL
Single Row Caged Needle Roller Bearing	35mm Bore Size	30mm Width	Cage Made from Glass Fibre Reinforced Polyamide	X-Life Bearing

Product Detailed Parameter

Brand:
Model:

NK35/30-TV-XL
Availability:

IN STOCK
Type:

Needle Roller Bearing
d - Inside diameter (mm):

35 mm
D - Outside diameter (mm):

45 mm
B - Width (mm):

30 mm
Weight (Kg):

0.105 Kg
Seals or shields:

Open Type
Clearance:

Standard
Basic dynamic load rating (KN):

46
Basic static load rating (KN):

81
Fatigue load limit (KN):

15.3
Reference speed (r/min):

7100
Limiting speed (r/min):

12900
Under Roller Diameter (MM):

35
MAX. Operating Temperature:

120°C/248Â°F
MIN. Operating Temperature:

-20°C/-4Â°F
IKO Equivalent:

TAF354530
