RNAO30X40X17-XL INA Machined Needle Roller Bearing - 30X40X17MM

  • Brand:
  • Model:

    RNAO30X40X17-XL

  • Availability:

    IN STOCK

  • Trade Terms:

    CIF

  • Payment Terms:

    100% T/T or Western Union or PAYPAL in advances

  • Delivery Terms:

    1-3 working days upon your payment

  • Shipping Terms:

    Express Delivery or Air or Sea

  • Price:

    Please contact Email sales@hensenbearing.com

  • We can provide the certificate of origin to ensure genuine products.Fast delivery , 3 years warranty

  • The real photos haven't been uploaded yet,please contact us by phone or email to view our detailed actual pictures.

We are a one-stop supplier of high quality bearings. We can supply the best products at the lowest price.

Product Description

The RNAO30X40X17-XL is a Light Duty Open Type, Single Row Machined Needle Roller Bearing. This Bearing has no Inner Ring, meaning the Needle Rollers are mounted directly onto the shaft. As such, the Bearing has better running accuracy as it isn't affected by assembling an Inner Ring with the shaft. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution and the Cage is separable from the Outer Ring. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The bearing dimensions are 30X40X17mm.

RNAO 30 40 17 XL
Single Row Caged Needle Roller Bearing 30mm Bore 40mm OD 17mm Width X-Life Bearing

Product Detailed Parameter

  • Brand:
  • Model:
    RNAO30X40X17-XL
  • Availability:
    IN STOCK
  • Type:
    Needle Roller Bearing
  • d - Inside diameter (mm):
    30 mm
  • D - Outside diameter (mm):
    40 mm
  • B - Width (mm):
    17 mm
  • Weight (Kg):
    0.06 Kg
  • Seals or shields:
    Open Type
  • Clearance:
    Standard
  • Basic dynamic load rating (KN):
    22.1
  • Basic static load rating (KN):
    54
  • Fatigue load limit (KN):
    3.4
  • Reference speed (r/min):
    8800
  • Limiting speed (r/min):
    15100
  • Under Roller Diameter (MM):
    30
  • MAX. Operating Temperature:
    120°C/248°F
  • MIN. Operating Temperature:
    -30°C/-22°F
  • IKO Equivalent:
    RNAF304017
